DGT / DGT60 / DGTQ / DGTP
21
- For the transmission modes and protocol specifications, see the 6.4 "SERIAL PORTS TRANSMISSION
MODES" and 6.6 "TRANSMISSION PROTOCOLS" sections.
o bAud SET BAUD RATE
By pressing the PRINT key one accesses the selection of the data transmission speed (measured in Baud
= bit/second). The possible values are:
1200, 2400, 4800, 9600, 19200, 38400, 57600,115200
(!) 9600
o bit SET PARITY, WORD, STOP BIT
By pressing the PRINT key one accesses the selection of the available values:
n-8-1, n-8-2, n-7-2, E-7-1, E-7-2.
(!) n-8-1
o (§) CoMPAt ENABLE THE “DGQ” COMMUNICATION PROTOCOL (visible only in the DGTQ model)
This step allows to enable the communication protocol compatibel with the DGQ series indicator; for the
description of this protocol and the relative set of commands, refer to the technical manual of the DGQ
indicator.
yES: enabled compatibility
no: disabled compatibility
NOTE: by enabling the compatibility, only the commands of the “DGQ” protocol will be available; the
commands shown in this manual will be automatically disabled.
(!) no
o Add.En ENABLING AND SELECTING THE 485 SERIAL ADDRESS (§)
In the rEPE functioning mode, through the FmodE >> FunCt parameter it is possible to enable the 485
protocol and links its own address to the instrument; the indicator will repeate the weight if the address in
the received string is the same as the address set here.
- no = 485 protocol disabled.
- YES = 485 protocol enabled.
If one enables the 485 protocol, one is asked to enter the 485 address, on the display appears the
message Adr-XX in which XX is the 485 address, from 00 to 99 (by pressing the TARE or ZERO keys one
increases the digit,and with MODE it’s selected; when the chosen values is reached, one confirms with
PRINT).
(§) The parameter is displayed in the DGT and DGT60 models, if one has selected the rEPE functioning
mode, FmodE >> FunCt parameter.
•
(*) ini.AL INITIALIZES ALIBI MEMORY (§)
The initialisation cancels all the data stored in the Alibi memory; by pressing PRINT one is asked to confirm the
operation. The display shows "iALib?"; press PRINT again to confirm or another key to cancel.
At the end the " AL.OK " message appears if the operation is made with success; otherwise the " AL.ERR"
message is displayed.
(§) The parameter is displayed only if the ALIBI functioning mode is selected, FmodE >> FunCt >> Alibi
parameter.
(*) The parameter is not displayed with an approved instrument.
• (*) dSALE LIMITATION OF THE SCALE FUNCTIONS
no limitations disabled
yES limitations enabled
Refer to the user manual for the description of its functioning (USER MAN.REF.).
(!) no
(*) The parameter is not visible with an approved instrument or if one has selected the rEPE or MAStr functioning
modes, FmodE >> FunCt parameter.
