DGT / DGT60 / DGTQ / DGTP
22
• inPutS INPUT CONFIGURATION
In this step one sets the function to link to each input (n°2).
inP.1 INPUT 1
o nonE Disabled
o ZEro ZERO Key
o tArE TARA Key
o ModE MODE Key
o Print PRINT Key
o C C Key ON/OFF for DGT60 model); the simple pressing of the indicator key will be repeated
o oFF TURNING OFF THE INDICATOR
o diS.kEy DISABLING OF KEYBOARD
(!) nonE
inP.2: INPUT 2
The programming of the 2 input is done as described for input 1.
NOTE: In case various inputs are simultaneously enabled just the one with the lower number is taken
into consideration.
• outPut OUTPUT CONFIGURATION
In this step one sets the function to be linked to each output (n°2).
out.1 OUTPUT 1
O FunC OUTPUT FUNCTION
0 nonE No function
1 GroS Set point on the Gross Weight
2 nEt Set point on the Net Weight
3 PCS Set point on the Pieces
4 Gro.0 Gross Weight at zero
5 nEt.0 Net Weight at zero
6 Moti. Instability
23 k.Pr Pressing of the PRINT key
25 k.Mo Pressing of the MODE key
26 k.C Pressing of the C - ON/OFF Key
27 k.ZE Pressing of the ZERO Key
28 k.tA Pressing of the TARE Key
29 Err ERROR INDICATION
o no/nC NO/NC CONTACTS
no output 1 normally opened.
nC output 2 normally closed.
(!) no
o onStAt SWITCHING CONDITION
drCt the output is activated as soon as the weight reaches the set threshold, (independently from the
stability) and is disabled in the moment in which the weight goes below the set disabling threshold.
StbL the output is activated in the moment in which the weight, after reaching the set activation
thresholds, becomes stable and is disabled in the moment in which the weight goes below the set
disabling threshold, it becomes stable.
(!) drCt
o rL.iSt HYSTERESIS
iSt.oFF disabled Hysteresis
iSt.on enabled Hysteresis
(!) iSt.oFF
