DGT / DGT60 / DGTQ / DGTP
24
o
AoMin MINIMUM VALUE
Setting of the minimum value of the analogue output.
o SiGn SIGN (§)
PoSit Functioning with positive weight.
nEGAt Functioning with negative weight.
(§) The parameter is displayed only if one has selected the operating mode on the Net Weight.
See the 7 "ANALOGUE OUTPUT (DGT4 AN and DGTQ AN)" section for configuring it.
• dEFAu INITIALIZATION OF THE INSTRUMENT
Through this step one can initialize the instrument with the subsequent activation of the default parameters. By
pressing PRINT, a confirmation message ("dFLt?) will appear: confirm again with PRINT or exit with any other
key.
NOTE: The initialization of the instrument causes a cancellation of the present calibration and the
activation of the default parameters. In any case if one exits the setup environment WITHOUT
CONFIRMING the modification made, all the parameters of the last saving made will remain (including
the calibration).
In case of approved instrument, the default DOES NOT HAVE EFFECT on the metrological parameters
(those marked with (*) ).
diAG DIAGNOSTICS MENU
It is a
submenu inside which it is possible to check the software components and the scale hardware.
PrG.Ver CHECKING THE SOFTWARE VERSION
By pressing PRINT the instrument shows the software version in the XX.YY.ZZ. format.
diV.int CALIBRATION INTERNAL DIVISIONS(§)
By pressing PRINT the instrument shows the calibration internal divisions.
(§) The parameter is not displayed if one has selected the rEPE or MAStr functioning mode, FmodE >> FunCt
parameter.
AdC.uV MICRO VOLTS (§)
By pressing PRINT the instrument shows the micro volts relative to the weight on the scale.
With the ZERO and TARE keys it is possible to switch the visualisation of the microvolts for each configured
channel of the scale. In the "DEP.CH." mode it is also possible to view the sum of the microvolts of the configured
channels ("SuM" appears for a few instants).
NOTE: The maximum voltage that the instrument accepts in input is 30 mV (30000
µ
V); the weighing system is
powered by the indicator at 5 Vdc.
A correct operation will have a value less than 30000 with a weight of full scale capacity on the weighing system.
(§) The parameter is not displayed if one has selected the rEPE or MAStr functioning mode, FmodE >> FunCt
parameter.
AdC.MVV MILLIVOLTS (§)
By pressing PRINT the instrument displays the millivolts relative to the weight on the scale.
Through the ZERO and TARE keys it’s possible to switch the display of the millivolts fot each configured channel
of the scale. With the MODE key one can execute the scale zero, while with PRINT one cancels.
AdC.Pnt CONVERTER POINTS
By pressing PRINT the instrument shows the A/D converter points relative to the weight on the scale.
With the ZERO and TARE keys it is possible to switch the display of the A/D converter points for each scale’s
configured channgel. In the "DEP.CH." mode, it is also possible to view the sum of the microvolts of the
configured channels ("SuM" appears for a few instants).
(§) The parameter is not displayed if one has selected the rEPE or MAStr functioning mode, FmodE >> FunCt
parameter.
