DGT / DGT60 / DGTQ / DGTP
41
Scale information reading: [CC]RALL<CR LF>
Instrument answer:
SS,B,NNNNNNNUM,LLLLLLLUM,YYTTTTTTTTUM,XXXXXXXUM,SSS,AAA,CCC,TTT,XXXXX-YYYYYY<CR LF>.
in which:
SS UL Underload
OL Overload
ST Stability of the display
US Unstability of the display
TL Active inclination input
B Number of platform on which the totalisation has been made.
NNNNNNNUM Net weight with unit of measure.
LLLLLLLUM Gross weight with unit of measure.
XXXXXXXUM Last net weight totalized with unit of measure
SSS Scale status: 000 normal scale status
001 normal scale status in input
002 instrument in boot phase
003 instrument in boot phase
004 instrument in rx/tx set-up phase
005 instrument in test phase of the serial ports
006 instrument in print test
007 instrument in firmware update phase
008 instrument in stand-by
009 instrument in automatic zero phase
010 instrument in change channel
011 instrument in input test phase
AAA Counter of pressed keys.
CCCC Code of last key pressed.
TTT Counter of totalisations.
XXXXX Last rewriting number stored in the Alibi memory.
YYYYYY Last weigh number stored in the Alibi memory.
Set point command
[CC]STPTntxxxxxxtyyyyyy<CR LF>
in which: n indicates the SET POINT number (1, 2)
t F if the following weight value indicates the DISABLING of the outputs (OFF).
t O if the following weight value indicates the ENABLING of the outputs (ON). xxxxxx and yyyyyy take on the set
point value of disabling or enabling: the digits must be entered WITHOUT the decimal point, omitting the NON
significant zeros.
Instrument responses: [CC]OK<CR LF> in case of syntax and correct values.
[CC]NO<CR LF> in case of correct syntax but wrong values.
Example of instrument with capacity 10,000 kg and division 1 g:
Command: STPT1F5000O6500 (Disabling first output at 5 kg and enabling at 6,5 kg)
Response: OK
