VEVOR L4040 - Parts List

Part No Part Name Explanation Quantity Picture
01 Portal frame component Already assembled 1Set
02 Aluminum profile (X) 2040*480mm 2
03 Aluminum profile (Y) 2020*555mm 2
04 L-shaped connector L-shape 4
05 Acrylic plate B for X-Part —— 1
06 Leg —— 4
07 Fixed wire block —— 1
08 Synchronous belt 2GT，length 620mm 2
09 Inner hexagon screw M5*8 10
10 Inner hexagon screw M5*10 1
11 Set screw M5*6 12
12 Square nut M5 12
13 Manual nut M5 4
14 Ship nut M5-10 3
15 Control board package VIGO-13 1
16 Wiring harness and protective pipe —— 1Set /
17 Cable ties —— 8
18 Power supply and power line 12V DC 1Set
19 Inner Hexagon Wrench 4/2.5/2mm 1Set
20 Nut Wrench 8# 1
21 USB cable —— 1
22 Protective glass —— 1
23 Non-slip mat —— 1 /
24 Instruction manual —— 1 /
L1 Laser kit Optional 1Set /
M1 Inner hexagon screw M3x6 4
C1 Control board VIGO-13 1 /
C2 Acrylic plate for control board A —— 1
C3 Acrylic plate for control board B —— 1
C4 Column Φ3*7 4
C5 Inner hexagon screw M3×18 4
C6 Nut M3 4
4040 Parts List
Laser package（Optional）
Control board package（15）
2/6
4040：V1.0
1. Parts List
2/7
L4040 V1.0
