VEVOR L4040 - Machine Assembly

02: Aluminum profile
2040*480mm 2PCS
03: Aluminum profile 2020*555mm 2PCS
04: L-shaped connector 1PCS
11: Set screw M5*6 2PCS
①
②
3/6
2. Machine Assembly
Connector component 4Set
12: Square nut M5
02: Aluminum profile 2040*480mm
03: Aluminum profile 2020*555mm
Connector component 4Set
12: Square nut
M5 4PCS
08: Synchronous
belt 620mm
01: Portal frame component
03: Aluminum profile 2020*555mm
03: Aluminum profile 2020*555mm
Stepper motor Y
11: Set screw M5*6 4PCS
08: Synchronous belt 620mm 2PCS
③
01: Portal frame component 1Set
Stepper motor X
4040：V1.0
12: Square nut M5 2PCS
D
i
r
e
c
t
i
o
n
o
f
c
o
n
n
e
c
t
i
n
g
w
i
r
e
D
i
r
e
c
t
i
o
n
o
f
c
o
n
n
e
c
t
i
n
g
w
i
r
e
3/7
L4040 V1.0
