VEVOR LB100T - Basic Structure Overview; Component Identification

- 7 -
3
Ice Maker
Drainage Pipe
Ice Maker Drainage Hose (2m)
1
4
ice Maker Water
Inlet Pipe
Connect to Ice Maker for Water
Inlet
2
5
Sealing Tape
Against Leakage when
Connecting Water Pipe
1
6
Sink plug
Block the sink
1
7
Drainage Pump
Help Ice Storage Bin Drains
Water When in Elevated Terrain
1
Some models do not include drainage pumps
BASIC STRUCTURE
