11. tailstock Clamping screw
Turn hex nut clockwise to lock and
counter-clockwise to unlock.
12. tailstock Quill Clamping Lever
Rotate the lever clockwise to lock the
spindle and counter-clockwise
to unlock.
13. tailstock Quill Traverse Handwheel
Rotate clockwise to advance the quill.
Rotate counter-clockwise to retract the
quill.
14. tailstock off-set Adjustment
Three sets screws located on the tails stock base are used to off-set the tailstock
for cutting tapers. Loosen lock screw on tailstock end. Loosen one side set screw
while tightening the other until the amount of off-set is indicated on scale. Tighten
lock screw.
