Viadrus K4 - FLEX 2 x D 80 mm Ducting Diagram

Servicing
41
11.3.2 FLEX, 2 x D 80 mm flue ducting diagram
Fig. . 29
Option 1 Option 2
Rain-protection collar
Terminal pipe without socket
Terminal pipe flex
Plastic chimney capital flex
(complete set)
Plastic chimney capital starr
(complete set)
Universal distance clamp
Inspection door
Ventilation grill
Inspection T-piece flex/starr
Inspection T-piece flex/flex
Flexible pipe
Adapter starr/flex
Foot-elbow starr 87° with anchoring
Inspection
T-piece with
drainage and
change of direction
- flex
Long John siphon
(for overpressure)
Adaptor starr/flex
87°
