11.5 Pressure Losses of Chimney Flue Elements in Case of VIADRUS K4 Boiler Usage
Maximal pressure of fan 150Pa
Multi-piece Chimney Flue - Burnt Gases K4GXH24XX K4GXH33XX
VIADRUS Code Code DN Name Loss in Pa
20105 PPSB48 80 Angle piece 45° 1,1 2,0
20107 PPSB98 80 Angle piece 87° 1,7 2,8
20133 PPRM18 80 Tube 1m 3,4 5,7
20111 PPSAS8 80 Chimney plastic head - starr (a set] 2,5 4,2
Multi Piece Chimney Flue - Suction
VIADRUS Code Code DN Name Loss in Pa
20105 PPSB48 80 Angle piece 45° 0,8 1,3
20107 PPSB98 80 Angle piece 87° 1,2 1,9
20133 PPRM18 80 Tube 1m 2,5 3,6
Concentric Chimney Flue
VIADRUS Code Code DN Name Loss in Pa
20158 LPBK45 60/100 Angle piece 45° 5,3 7,8
20160 LPBK95 60/100 Angle piece 87° 7,5 11,1
20199 LPRK15 60/100 Tube 1m 21,9 32,8
20197 LPZTK5 60/100 LIK T-piece for air inlet 5 7,5
20235 LPASK5 60/100 LIK tube piece for façade chimney flue 10,5 17,1
20221 DPDS45 60/100 Roof extension (a set) 29,8 45,1
20159 LPBK48 80/125 Angle piece 45° 1,5 2,5
20161 LPBK98 80/125 Angle piece 87° 2,1 3,5
20202 LPRK18 80/125 Tube 1m 5,4 8,3
20198 LPZTK8 80/125 LIK T-piece for air inlet 1,5 2,4
20236 LPASK8 80/125 LIK tube piece for façade chimney flue 3,5 5,4
20225 DPDS48 80/125 Roof extension (a set) 9,1 14,0
20169 FVIA01 60/100-80/125 LIK boiler reducer 2 3,2
12 Commissioning
The entire installation shall comply with the regulations that are applicable for this equipment. The boiler shall be compatible with the local
connecting conditions (checking the parameters of the boiler with the information on the name plate). The boiler can only be commissioned
by organizations that are authorized and trained for this purpose by the manufacturer. The minimum pressure in the heating system is
0,8 bar. It is necessary to open all closing valves and make sure that no gas is leaking. Connect the boiler to the electric power mains. Check
the gas distribution line after the gas valve. Check the safety valve function. Then check the pump operation. During the operation of the boiler it
is necessary to check removal of the condensate from the boiler and also from the chimney lining, if applicable.
During the first start of operation of the boiler it is necessary to train the user in accordance with this manual and to hand over this
manual to the user.
Then it is necessary to perform:
- inspection revision before commissioning,
- inspection for any water leakages,
- inspection of instrumentation and safety controls.
