Viadrus K4 - K4 GXH33 X Honeywell Parameters

Servicing
49
12.4.2 K4GXH33X - Honeywell electronics parameters set in the manufacturing factory
(service parameters list neXsys S4962V3224)
Parameter
Name
Renge
Unit
Setting Setting
K4G1H33Z. K4G2H33Z. K4G3H33Z.
K4G1H33P
K4G2H33P. K4G3H33P.
P00
DHW configuration
1= Instantaneous
num. 5 1 3 5 1 3
2= Instantaneous + Solar
3= Storage tank
4= Solar storage tank
5= CH only
P01
Gas type
0=Natural
num. 0 0 0 1 1 1
1=LPG
P02
Ignition fan speed
150-635 rpm/min x 10 400 400 400 400 400 400
P03
Water filling 0= Enable
num. 0 0 0 0 0 0 1= Disable
2=Auto
P04
DHW user set point max. 30-65 °C x 65 65 x 65 65
P05
DHW maximum fan speed 150-635 rpm/min x 10 x 635 635 x 635 635
P06
DHW minimum fan speed 150-635 rpm/min x 10 x 150 150 x 150 150
P07
DHW pump overrun time 0 - 255 min. x 1 1 x 1 1
P08
DHW frost protection ON 0 - 50 °C x 8 8 x 8 8
P09
DHW frost protection OFF 0 - 50 °C x 35 35 x 35 35
P10
DHW heat demand type 0=sensor
num. x x 0 x 0 x
1=thermostat
P11
DHW antilegionella set point 0 - 70 °C x x 70 x 70 x
P12
DHW antilegionella timeout 1 - 7 day x x 7 x x 7
P13
Supply temperature delta 0 - 20 °C x x 5 x x 5
P14
Maximum supply temperature 0 - 90 °C x x 85 x x 85
P15
Solar enable temperature 5 - 20 °C x x x x x x
P16
Solar disable temperature 5 - 20 °C x x x x x x
P17
Solar pump min. running time 0 - 120 sec. x x x x x x
P18
Solar limit temperature 100 - 150 °C x x x x x x
P19
Solar storage tank limit
temperature
50 - 100 °C x x x x x x
P20
Solar mode functionality 0= 0=solar priority
num. x x x x x x
1= parallel
P21
Heat demand delay after Solar
pump activation
0 - 60 sec. x x x x x x
P22
Delta for virtual DHW user set
point
0 - 30 °C x x x x x x
P23
CH user set point maximum 20 - 90 °C 80 80 80 80 80 80
P24
CH maximum fan speed 150-635 rpm/min x 10 635 635 635 635 635 635
P25
CH minimum fan speed 150-635 rpm/min x 10 150 150 150 150 150 150
P26
CH OFF time 0 - 10 min. 1 1 1 1 1 1
P27
CH pump overrun timer 0 - 255 min. 3 3 3 3 3 3
P28
CH pump 0= Continuous
num. 0 0 0 0 0 0
1= Overrun
P29
CH minimum time 0 - 5 min. 1 1 1 1 1 1
P30
CH slope rate 0-60 °C/min. 4 4 4 4 4 4
P31
CH frost protection ON 0 - 10 °C 5 5 5 5 5 5
P32
CH frost protection OFF 0 - 10 °C 10 10 10 10 10 10
P33
OTC curve selection 0 - 30 num. 0 0 0 0 0 0
P34
Supply for CH thermostatic
pump overrun OFF
0 - 100 °C 80 80 80 80 80 80
P35
Supply for CH thermostatic
pump overrun ON
0 - 100 °C 85 85 85 85 85 85
P36
System configuration Bit x: cleared / set
num. 4 4 4 4 4 4
Bit 2: WP switch / sensor
P37
DHW request type 0= Fugas Flow sensor
num. x 3 x x 3 x
1= Bitron Flow sensor
2= Kramer Flow sensor
3= Flow switch
2= Honeywell Flow sensor
