86 OLP-87/OLP-87P
14 SPECIFICATIONS
GENERAL SPECIFICATIONS
Broadband power meter mode
1310/1490 nm version only
EMC, calibration
PS4 Universal AC/DC Power Supply
Condensation – even occasional – is not tolerable.
Weight 750 g
Operating temperature range -5 °C to +45 °C
Storage temperature range -25 °C to +55 °C
Power measurement range -50 to +13 dBm
Max. permitted input level +15 dBm
Power uncertainty (2 )± 0.5dB
1)
2)
1) At 23 °C ±3 °C, at 1270/1310/1490/1550/1578 nm
2) Approx. -7 dBm
Power uncertainty (3–5 ) ± 0.2 dB (± 5%)
Wavelength (range) 1260 to 1625 nm
Calibrated wavelengths 1310, 1490, 1550 and 1625 nm
Wavelength settings 1260 to 1625 nm in 1 nm steps
EMC Standard
Emission
Immunity
IEC 61326:2002
Class B Equipment
IEC 61326, Table 1
Recommended
calibration interval
3 years
Power supply type FW 75550/12
Nominal line voltage range 100 to 240 VAC
Nominal line frequency range 47 to 63 Hz
Power consumption Max. 8.5 W
Output 12 V DC / 2 A
Temperature range 0 to +40°C
