Vicon Extra 224 - Page 16

Assembly
16
 Place the tarpaulin over the frame as shown .

Fit the end frames “A”, ”B” and the edging “C” and
fasten the tarpaulin.
M10 x 25
ø10,5-ø20x2
2620: 8 pcs.
2624: 8 pcs.
2628: 10 pcs.
2632: 10 pcs.
2620: 8 pcs.
2624: 8 pcs.
2628: 10 pcs.
2632: 10 pcs.
D
E
F
M10 x 30 (4 pcs.)
ø10,5-ø20x2 (4 pcs.)
M10 x 25 (3 pcs.)
ø10,5-ø20x2 (3 pcs.)
A
B
C
F
E
D
M10
Lock Nut (4 pcs.)
M10
Lock Nut (3 pcs.)
M10 Lock Nut
2620: 8 pcs.
2624: 8 pcs.
2628: 10 pcs.
2632: 10 pcs.
