Ball Drip
Plunger
Auto Vent
Sleeve of
Series 776
Low-Pressure
Actuator
Alarm
Test
Ball
Valve
Charge
Line
Ball
Valve
Auto Drain
Sleeve
Water
Supply
Main Drain
Valve
Water Supply
Main Control
Valve
System
Main
Drain
Valve
WATER FLOW ALARM TEST
Perform the water flow alarm test on a frequency required by the current NFPA-25 code or LPCB/EN guidelines. The authority having jurisdiction in the
area may require these tests on a more frequent basis. Verify these requirements by contacting the authority having jurisdiction in the affected area.
1. Notify the authority having jurisdiction, remote station alarm monitors, and those in the affected area that the water flow alarm test will be
performed.
2. Open the water supply main drain valve fully to flush the water supply of any contaminants.
3. Close the water supply main drain valve.
4. Open the alarm test ball valve. Confirm that mechanical and electrical alarms are activated and that remote monitoring stations, if provided,
receive an alarm signal.
5. Close the alarm test ball valve after verifying proper operation of all alarms.
6. Push in the ball drip plunger on the alarm manifold assembly to verify that there is no pressure in the alarm line.
7. Verify that all alarms stopped sounding, that the alarm line drained properly, and that remote station alarms reset properly.
8. Confirm that the ball drip on the alarm manifold assembly is not leaking water or air.
9. Provide test results to the authority having jurisdiction, if required.
