Victor iCNC XT - Motor and Encoder Polarities

iCNC XT
Manual 0-5299 INSTALLATION 3-21
3.17 Motor and Encoder Polarities
NOTE
Make sure the Drive Enable Switch on the front of the controller is “OFF”
Make sure that the controller is in basic status (no lights-on in any of the 10 push buttons in front panel.)
CAUTION
Disengage all motors from rails before doing the motion test. Disregarding this may result in mechanical damage.
Select 1.2. Drive and Encoder Polarities from iCNC Setup.

2. Opening this dialog box opens the positioning loop. Press Y+, Y-, X+, X- buttons to send out speed signals to the drives and check the
actual rotation of the drive pinion wheels. If rotation is incorrect, change the corresponding polarity in the dialog box and check again.

4. Next, set the encoder polarity by pressing the Y+ direction for about 2 seconds. If the polarity is incorrect, the software will automati-


