iCNC XT
Manual 0-5299 OPERATION 5-19
5.7 XT211/231 Switch Description and Functions
5.7.1 Station Select Switches
NOTE:
Switches Not available in XT211 (See blue box on the picture above)
Station Select Switches 1 – 3.
With the STATION SELECT switches the operator can select which Oxy Fuel torches are in use.
The switches have 2 positions: Up/On, Down/Off
OFF for Oxy-Fuel stations 1 – 3:
• A station is not selected
• Preheat gases, cutting oxygen, water spray, ignition and pierce signals are disabled for this torch
• Torch Up and Down switches for this torch are disabled
• All Up / Down switch does not effect this torch
ON for Oxy Fuel stations 1-3 means that:
• Torch Up and Down switches for this torch are enabled
Preheat gases, cutting oxygen, water spray and ignition are disabled for this torch
• All Up / Down switch will drive this torch
Main gas signal will always activate even when all station select switches are Off.
