iCNC XT
5-20 OPERATION Manual 0-5299
5.7.2 Up / Down Switches
All Up / Down switch, (See bottom right most box “OXYFUEL”on the picture above)
The All Up / Down switch, drives all the selected stations up and down.
NOTE:
Switches Not available in XT211 (See yellow box on the picture above)
Individual Up / Down switches (See “PLASMA” bottom right and “1,2,3” upper right on the picture above)
The Individual Up / Down switches will drive the corresponding station up or down, if the station is selected.
5.7.3 Cutting Oxygen On/Off/Auto Switch
• ON position will open the cutting oxygen solenoid
• AUTO position will allow the cutting program to open the cutting oxygen solenoid when necessary
• OFF position will prevent the cutting program from opening the cutting oxygen solenoid valve.
