iCNC XT
Manual 0-5299 OPERATION 5-7
5.3.3 Manual Mode Button
Pressing the MANUAL MODE button activates the capability to jog and reposition the machine.
CAUTION
Pressing the MANUAL MODE button again will turn off the manual mode and will return the machine to the last know parked position.
5.3.4 Zero Button
Resets the X & Y counters to ZERO after locating a new starting point on the table using the jog function keys.
HINT: Pressing the zero button will automatically turn off the manual mode button, if it was activated on.
5.3.5 Start Button
Sends the cutting program from the “next job preview” screen to the “current job” screen to be executed, and starts the cutting cycle
sequence. The START- button illuminates and is on during the entire execution of the program. No programs can be transferred
to the current job screen if the START button is on.
HINT: If this button is pressed during a programmed delay, the delay is terminated at once without memorizing the interrupted
time of the delay in cutting parameters.
