iCNC XT
5-14 OPERATION Manual 0-5299
5.6.2 Up / Down Switches
All Up / Down switch (See upper box on the picture above)
All Up / Down switch drives all the selected stations up and down.
Individual Up / Down switches (See lower box on the picture above)
Individual Up / Down switches will drive the corresponding station up or down, if the station is selected.
5.6.3 Cutting Oxygen On/Off/Auto Switch
• ON position will open the cutting oxygen solenoid
• AUTO position will allow the cutting program to open the cutting oxygen solenoid when necessary
• OFF position will prevent the cutting program from opening the cutting oxygen solenoid valve.
