iCNC XT
5-16 OPERATION Manual 0-5299
5.6.6 Marker On/Off/Auto Switch
• ON position will activate the marker. This is used for testing.
• AUTO position will be used when a cutting program includes marking.
• OFF position will prevent activating the marker from a cutting program.
Please note also the marker down switch usage.
5.6.7 Plasma On/Off/Auto Switch
• ON position will activate the plasma. This is used for testing.
• AUTO position allows the plasma cutting signal from a program to run the plasma.
• OFF position will prevent activating the plasma.
NOTE:
Some height controllers start the plasma by themselves. See IHS switch usage.
IMPORTANT: Please note the Marker Down (M.DOWN) switch usage.
