1.6
SPECIFICATIONS / GAUGE / AUDIO
© Copyright 2012 Polaris Sales Inc.
9924047 - 2012-2013 VICTORY Cross Roads / Cross Country Service Manual
2012-2013 Cross Roads Classic™ / Hard-Ball™
Specifications may change with the addition of custom order options and / or accessories. Polaris Sales Inc. reserves the right without prior notice
to discontinue at any time at its discretion any of the items herein or change specifications or designs without incurring any obligation to the customer.
D
R
I
V
E
S
Y
S
T
E
M
Cross Roads Classic Hard-Ball
Transmission Type Manual, 6 Speed Constant Mesh with True Overdrive
Clutch Type Wet, Multi-Plate, Diaphragm Spring
Primary Drive Type Wet, Gear Drive w/ Torque Compensator
Primary Reduction Ratio 1.48:1
Final Drive Type / Belt Width /
Final Drive Ratio
Carbon Fiber Reinforced Belt / 28mm / 2.12:1
Gear Shift Pattern 1 Down, 5 Up
Internal Gear Ratios 1st 3.13:1
2nd 2.02:1
3rd 1.50:1
4th 1.20:1
5th 1:1
6th .87:1
S
U
S
P
E
N
S
I
O
N
Front Wheel (Size / Type) Spoke Type - 3.50 X 18”
Rear Wheel (Size / Type) Spoke Type - 5.00 X 16”
Front Tire Dunlop 491 Elite II - 130/70-18 63H Bias-Ply (Tube Type)
Rear Tire Dunlop D418 Elite 3 - 180/60R16 M/C 80H Radial (Tube Type)
Minimum Tread Depth .063 in. (1.6mm)
Front Type Inverted Telescopic Cartridge Fork
Front Travel 5.1 in. (13 cm)
Front Tube Diameter 43 mm (1.7 in.)
Rear Shock Type Single, Monotube Air Adjustable Shock
Rear Swingarm Type Cast Aluminum with Constant Rate Linkage
Rear Travel (inches) 4.7 in (12 cm)
L
I
G
H
T
S
Headlamp High H-11 55W / Low: H-11 55W
HID Headlamp (If equipped) High H-11 / Low: D1SR
Turn Signal Lamp Non-Serviceable LED
Brake / Tail / License Plate Lamp Non-Serviceable LED
Alternator / Battery 625W (48A @ 13.0VDC) / 12V 18AH 310 CCA
F
U
S
E
S
Turn Signal / Horn 10 amp fuse
Chassis 20 amp fuse
Engine 15 amp fuse
Fuel Pump / Ignition Coil 15 amp fuse
Ignition 10 amp fuse
Lights 20 amp fuse
Circuit Breakers See fuse box label (Chapter 2)
F
U
E
L
Fuel Type Premium Unleaded / 91 Octane Minimum
Fuel Pump Pressure 3.51 BAR (351 kPa) (51 psi)
Fuel Pump Volume (Approx. @ 12 V)
60 liters / hr (500 ml or 16.9 oz. / 30 seconds) (0.26 gal / min)
Fuel Level Sensor Resistance Empty: 250 Ohms / Full: 50 Ohms
Fuel Pump Current Draw
Less than 5.0 Amps
Fuel Injector Resistance 11.4 - 12.6 Ohms
