Victrola Jackson - Unit Operations and Controls

OPERATIONS AND CONTROLS
FRONT VIEW
REAR VIEW
1 HEADPHONE JACK
2 AUX-IN JACK
3 USB PORT
4 CD DOOR
5 LCD DISPLAY
6 OPEN/CLOSE BUTTON (CD DOOR)
7 POWER/MODE BUTTON
8 PLAY/PAUSE BUTTON
9 STOP BUTTON
16 ANTENNA SOCKET
10 DN/F-R BUTTON
(BACK/REWIND)
11 UP/F-F BUTTON
(NEXT/FAST FORWARD)
12 PLAY MODE BUTTON
(PLAYBACK MODES)
13 RECORD BUTTON
14 VOLUME KNOB
15 TUNER/PRESET KNOB
17 POWER CORD
1 2 3 5 6 7 8 9 10 11 12 13 144 15
1716
4
