Victrola Jackson - Turntable and Remote Details; Turntable Layout

REMOTE CONTROL
TURNTABLE LAYOUT
1 RECORD
2 OPEN/CLOSE (CD DOOR)
3 EQ SETTINGS
4 VOLUME DOWN
5 PLAY MODE (PLAYBACK MODES)
6 PLAY/PAUSE
7 DN/F-R BUTTON
(BACK/REWIND)
8 STOP
9 PRESET
10 -10 TRACKS
11 PROGRAM
12 REPEAT PLAYBACK
13 RANDOM PLAYBACK (SHUFFLE)
14 MODE
15 VOLUME UP
16 UP/F-F BUTTON
(NEXT/FAST FORWARD)
17 +10 TRACKS
18 DELETE (USB)
19 MUTE
1
2 14
15
16
17
18
19
3
4
5
6
7
8
9
10
11
12
13
REPEAT
RANDOM
MODE
1 TRANSIT SCREW
2 LIFT LEVER
3 TONE ARM CLIP/REST
4 SPEED SELECTION SWITCH
5 TONE ARM
6 TURNTABLE PLATTER
7 45 RPM ADAPTOR
OVERHEAD TURNTABLE VIEW
5
1
2
6
7
3
4
5
