Victron energy Blue Smart IP65 Charger 12/4 User Manual

17
EN NL FR DE ES IT PT
5. Monitoring (Using VictronConnect)
The charger operation and recharge statistics can be closely monitored live or post
charging with a Bluetooth enabled device (such as a mobile phone or tablet) using the
VictronConnect app.
There are 3 different overview screens available (STATUS, GRAPH and HISTORY), each
displaying different monitoring or historical data; spanning back over the last 40 charge
cycles.
The desired screen can be selected by either selecting the window title or by swiping
across between screens.
5.1 Status screen
The STATUS screen is the main overview screen; it displays the battery voltage, the
charge current and the active charge stage.
This data will update continuously and in real time as the charge cycle progresses.

Victron energy Blue Smart IP65 Charger 12/4 Specifications

General

Input Voltage	100-240 VAC
Output Current	4 A
Battery Capacity	up to 100 Ah
Efficiency	85%
Charging Stages	Bulk, Absorption, Float
Bluetooth	Yes
Output Voltage	12V
Battery Type	Lead-acid, Lithium
Protection	Over-temperature, reverse polarity, short circuit
