7. TECHNICAL SPECIFICATIONS
Blue Smart IP65 Charger 12V 4/5/7/10/15/25A 24V 5/8/13A
Input voltage
230VAC
Efficiency
94%
95%
Standby power consumption
0.5W
Minimum battery voltage
Starts charging from 0V (dead battery)
Charge voltage 'absorption'
Normal: 14.4V
High: 14.7V
Li-ion: 14.2V
Normal: 28.8V
High: 29.4V
Li-ion: 28,4V
Charge voltage 'float'
Normal: 13.8V
High: 13.8V
Li-ion: 13.5V
Normal: 27.6V
High: 27.6V
Li-ion: 27.0V
Charge voltage 'storage'
Normal: 13.2V
High: 13.2V
Li-ion: 13.5V
Normal: 26.4V
High: 26.4V
Li-ion: 27.0V
Output current, normal mode
4 / 5 / 7 / 10 / 15 / 25A
5 / 8 / 13A
Output current, low current mode
2 / 2 / 2 / 3 / 4 / 10A
2 / 3 / 4A
Temperature compensation (lead-
acid batteries)
16mV/°C 32mV/°C
Charge algorithm
7-stage adaptive
Can be used as power supply
Yes
Back current drain
0.7Ah/month (1mA)
Protection
Reverse polarity (fuse), Output short circuit,
Over temperature
Operating temperature -30 to +50°C (full rated output up to 30°C)
Humidity (non condensing)
Max 95%
ENCLOSURE
Battery-connection
Black and red cable of 1.5 meter
230V AC-connection
Cable of 1.5 meter with
CEE 7/7, BS 1363 plug (UK) or AS/NZS 3112 plug
Protection category IP65 (splash and dust proof)
Weight
IP65 12V 25A 24V 13A: 1.9kg
Other: 0.9kg
Dimensions (h x w x d)
IP65s 12V 4/5A: 45 x 81 x 182mm
IP65 12V 7A, 24V 5A: 47 x 95 x 190mm
IP65 12V 10/15A, 24V 8A: 60 x 105 x 190mm
IP65 12V 25A, 24V 13A: 75 x 140 x 240mm
STANDARDS
Safety
EN 60335-1, EN 60335-2-29
Emission
EN 55014-1, EN 61000-6-3, EN 61000-3-2
Immunity
EN 55014-2, EN 61000-6-1, EN 61000-6-2, EN 61000-3-3

Victron energy Blue Smart IP65 Charger 12/4 Specifications

General

Input Voltage	100-240 VAC
Output Current	4 A
Battery Capacity	up to 100 Ah
Efficiency	85%
Charging Stages	Bulk, Absorption, Float
Bluetooth	Yes
Output Voltage	12V
Battery Type	Lead-acid, Lithium
Protection	Over-temperature, reverse polarity, short circuit
