7. Technical specifications
BlueSolar PWM-Pro charge controller 12/24V
5 A /10 A
20 A
30 A
Battery voltage
12/24V Auto Select
Rated charge
current
5 A / 10 A 20 A 30 A
Automatic load
disconnect
Yes
Maximum solar
voltage
28 V / 55 V (1)
Self-consumption
8 mA
DEFAULT SETTINGS
Absorption charge
14,4 V / 28,8 V
Float charge
13,8 V / 27,6 V
Equalization charge
14,6 V / 29,2 V
Low voltage load
disconnect
11,1 V / 22,2 V
Low voltage load
reconnect
12,6 V / 25,2 V
Load output
Manual control + low voltage disconnect
ENCLOSURE & ENVIRONMENTAL
Battery temperature
sensor
Optional
Temperature
compensation
-30 mV / °C resp. -60 mV / °C
(if temperature sensor installed)
Operating
temperature
-35
℃
to +50
℃
Cooling
Natural convection
Humidity
≤95% (non condensing)
Enclosure
IP30
Grounding
Positive grounding
Overall dimensions
138x70x37 mm
5.4x2.7x1.4 inch
160x82x48 mm
6.3x3.2x1.9 inch
200x100x57 mm
7.9x4.0x2.3 inch
Mounting hole size
Φ 4,3 mm
Φ 4,3 mm
Φ 4,5 mm
Terminal size
4 mm
2
10 mm²
10 mm²
Weight
0,13 kg
0,3 kg
0,5 kg
Mounting
Vertical wall mount, indoor only
STANDARDS
Safety
IEC 62109-1
EMC
EN 61000-6-1, EN 61000-6-3, ISO 7637-2
1) For 12 V use 36 cell solar panels
For 24 V use 72 cell solar panels, or 2x 36 cell in series
