Victron energy MultiPlus-II 12|3000|120-50 - Appendix C: Parallel connection

Appendix C. APPENDIX C: Parallel connection
Unit1: Master Unit2: Slave1 Unit3: Slave2
+ BAT - + BAT - + BAT -
PE
AC OUT2 N
AC OUT2 L1
AC OUT2 L2
PE
AC OUT1 N
AC OUT1 L1
AC OUT1 L2
PE
AC IN N
AC IN L1
AC IN L2
GX device
MultiPlus-II 12|3000|120-50 2x120V
Page 29 APPENDIX C: Parallel connection
