Videx 6200 Series User Manual

66251115 - V4.1 - 31/07/19
- 14 -
6200 Series
Art.6296 - Installation instructions
Art.6296
IP Videophone for VIDEX IP System
Main Entrance
Back Entrance
15:30
SELECT A CALL POINT
Fig. 55 Select the door panel to recall
15:30
MAIN MENU
Intercoms Address Book
Is Empty
Fig. 56 Intercoms Address Book is Empty
Ground Floor
First Floor
15:30
SELECT AN EXTENSION
Fig. 57 Select the extension to call
15:30
MAIN MENU
Remote Output List
Is Empty
Fig. 58 Remote Output List Is Empty
Pedestrian Gate
Car Gate
15:30
SELECT AN OUTPUT
Fig. 59 Select the relay to activate
Pedestrian Gate
Car Gate
15:30
SELECT AN OUTPUT
Pedestrian Gate
Fig. 60 Tap on tick button to activate the relay
