VK4K/6256 Series “6 wire Bus” videokit
VK4K/6256 Series - Installation handbook
VK4KC/6256 Colour videokit plus a codelock module.
50135,0
280,0
45,0 22,7
263,0
INDOOR
STATION
Videophone
Art.6256
pag. 20
OUTDOOR
STATION
Camera unit
Art.4833
pag. 8
Codelock
module
Art.4901
pag. 14
Flush
Mounting
Surface
Mounting
ACCESSORIES
Power supply
Art.850K
pag. 5
Video distributor
Art.316N
pag. 23
Fig. 3 - VK4KC/6256 components (measures in mm)
ONE WAY VERSIONS
VK4KC-1/6256 - ush mounting
1 Outdoor station composed of:
1 Art.4833-1: 1 button camera unit
1 Art.4901: Codelock module
1 Art.4852: Flush mounting box
1 Colour videophone
Art.6256
1 Power supply
Art.850K
VK4KC-1S/6256 - surface mounting
1 Outdoor station composed of:
1 Art.4833-1: 1 button camera unit
1 Art.4901: Codelock module
1 Art.4882: Surface mounting box
1 Colour videophone
Art.6256
1 Power supply
Art.850K
TWO WAY VERSIONS
VK4KC-2/6256 - ush mounting
1 Outdoor station composed of:
1 Art.4833-2: 2 button camera unit
1 Art.4901: Codelock module
1 Art.4852: Flush mounting box
2 Colour videophones
Art.6256
2 Power supplies
Art.850K
1 Video distributor
Art.316N
VK4KC-2S/6256 - surface mounting
1 Outdoor station composed of:
1 Art.4833-2: 2 button camera unit
1 Art.4901: Codelock module
1 Art.4882: Surface mounting box
2 Colour videophones
Art.6256
2 Power supplies
Art.850K
1 Video distributor
Art.316N
System components and available versions
