PAGE 12 of 32 DIGITAL GSM INTERCOM TECHNICAL MANUAL VER2.1.1
1 - ADD/EDIT or DELETE an Apartment
From the main menu page, press ‘1’ for APT then press either ‘1’ to add or edit an apartment, ‘2’ to
delete an apartment or ‘5’ to return to the main menu page.
ADD/EDIT
MEMORY LOCATION; Memory locations are between 0 & 999. The memory location is simply a
position in memory to store a single apartments/persons details.
TELEPHONE NUMBER; This is the first telephone number to be called when a user enters the
apartment number for this user. The telephone number can be up to 16 digits.
DIVERT NUMBER; If the first number is not answered or busy then this number will automatically
be called. The number can be up to 16 digits. Leave this blank if there is no number to divert to.
APARTMENT NUMBER; The apartment number is the number entered by the caller. The number
can be up to 6 digits/characters.
ACCESS CODE; Each user can have their own personal access code to gain enter to the
premises The access code can be up to 6 digits. When entered by a user it will activate the lock
relay for the programmed time period. Leave blank if not required.
DTO; It is possible to allow users to dial the telephone number of the panel to activate the lock
relay. To activate this feature enter ‘1’. To disable this feature enter ‘2’. When this feature is active,
a user calling from either the telephone number or divert number will activate the relay for the
programmed time. The call will then be dropped automatically. If this option is set to ‘2’, the call will
be dropped automatically.
TIMEBAND; A time band is used to set when a user can receive calls. For example a user may
only want to receive calls during certain hours of the day. There are 10 time bands available (0-9).
Time band 0 is set to all day (00:00 – 23:59) and cannot be changed where as all the other time
bands can be programmed.
APARTMENT NAME; The apartment name feature is only used on the scroll style panels. On this
type on panel it is possible for callers to scroll through these names on the panel. The names can
be up to 16 characters long. Entering these names is similar to sending a text on a mobile phone.
You use the numeric keypad as shown in the table below.
DELETE
MEMORY LOCATION; Memory locations are between 0 & 999. The memory location is simply a
position in memory to store a single apartments/persons details. Enter the memory location to
delete and press enter. All information in that memory location will be deleted.
2 - ADJUSTING SYSTEM TIMES
From the main menu page, press ‘2’ for TIMES then press either ‘1’ for call time, ‘2’ for divert time,
‘3’ for relay time, ‘4’ for aux out time or ‘5’ to return to the main menu page.
CALL TIME; The call time can be between 1 - 255 seconds. The call time starts from when the
enter button is pressed and is the time before the call automatically clears down.
DIVERT TIME; The divert time can be between 1 – 255 seconds. The divert time is the wait time
for a call to be answered before it attempts to divert the call to the stored divert number (If
available). If no number is stored, the call will continue with the first number until answered or the
call time expires.
RELAY TIME; The relay time can be between 1 – 255 seconds.
AUX TIME; The auxiliary output (AO) time can be between 1 – 255 seconds.
1 = <SPACE>.& 2 = ABC 3 = DEF
4 = GHI 5 = JKL 6 = MNO
7 = PQRS 8 = TUV 9 = WXYZ
ENTER = FINISHED 0 = +-*/ CLEAR = DELETE
