21
5712 717 v1.0
Vitotronic 100, KW10B Installation, Start-up and Service
Start-up
After Installation
Checklist
Please verify the following points (check with a pen) and
take corrective actions as necessary:
o Have all limit capillaries and sensors been completely
inserted into the boiler 5-point sensor wells?
o Have all electrical connections been made as
discussed in the previous section?
o Did all plug-in connectors engage with a “click” ?
o Have the settings of both the fixed high limit and
the adjustable high limit been checked and altered
as necessary?
Start-up Instructions
1. Check all connections
Based upon the Section entitled “Overview” on page
10, ensure all electrical connections have been made
according to the diagram.
2. Ensure settings on fixed high limit and adjustable high
limit are correct. See pages 17 to 18.
3. Ensure correct operational settings on control are set
Read Operating Instructions and User’s Information
Manual of Vitotronic.
The installer on the system is also responsible to
ensure the system operator/ultimate owner is made
familiar with the system functioning, its activation,
and its shut-down.
Service binder
1. File all technical documentation into the Service
Binder.
2. Install a protective service box (optional equipment)
near the boiler and store the Service Binder in this
location.
