Shut-off valve and flow rate indicator
A
B
1 2
4
3
A
Shut-off valve (adjusting screw)
1 Flushing
2 Draining
3 Flow rate regulation
4 Operating position (depicted in
the diagram)
B
Flow rate indicator
Check the flow rate at the top edge of
the float
20
5
15
25
10
35
30
l/min
Air separator
B
A
A
Air vent valve
B
Hose connection
Components (cont.)
