03.
Secure flexible flue B to chimney
connection plate
C
. See page 30.
04.
Push chimney connection plate C
upwards and secure. Do not
tighten the screws at this stage, so
the chimney connection plate can
be aligned when the Vitodens is
being fitted.
05.
Push balanced flue pipe D in
chimney connection plate
C
upwards by approx. 40 mm.
Installation in a disused chimney
(cont.)
5780 223 GB
