Viessmann Vitogate 300 - Fitting the Thermal Insulation; Boiler Shell Thermal Insulation

16
Boiler shell thermal insulation
2x
6x
3.
2.
4.
A A
A
1.
A
Black side outwards
Note on steps 2 to 4
Connect the thermal insulation mat with
an overlap.
Note
Before fitting the thermal insulation,
check that the serial number on the type
plate matches the serial number stam-
ped on the boiler front panel.
Fitting the thermal insulation
5614 451 GB
