18
Thermal insulation mats, back
1.
A
2.
B
A
Thermal insulation mat, back
B
Combustion chamber thermal insu-
lation mat
Note
The
actual
thermal
insulation
mats
deliv-
ered may differ from those shown here.
Fitting the thermal insulation
(cont.)
5614 451 GB
17
19
