Viessmann Vitogate 300 - Base Support and Levelling

8
Note
Base support
D
may be removed by
undoing four screws to make handling
easier.
When refitting the base support, tighten
the four screws with 70 Nm torque.
3.
3.
2.
F
1.
Insert adjusting screws F (inside the
bag on the boiler support) into the
base rails from the top.
2. Undo the timbers from the boiler
base.
Siting and levelling the boiler
(cont.)
5614 451 GB
