4.1 Specification
Rated output range kW 13 to 26 20 to 40
Permissible flow temperature ºC 100 100
Minimum return temperature ºC 45 45
Max. operating pressure
Boiler
Heat exchanger
bar
bar
3
6
3
6
CE designation
In accordance with the
Pressure Vessel Guideline
CE0036
Boiler class acc. to EN3035 3 3
Overall dimensions
Overall length
Overall width
Overall height
Transport dimensions
with transport protection
Length
Width
Height
mm
mm
mm
mm
mm
mm
1014
915
1
493
1
045
790
1
545
1014
915
1
693
1
045
790
1
745
Total weight kg
Boiler shell with thermal insulation
580 650
Weight  boiler body kg 543 629
Max. elec. power consumption W 120 120
Contents
Boiler water
Fuel hopper
litres
litres
71
150
93
215
Boiler connections
Boiler flow and return plus G(female thread) 1¼" 1¼"
safety connection
(safety valve)
Drain R(male thread) ½" ½"
Heat exchanger connections
Cold water, hot water R(male thread) ¾" ¾"
Primary side
Flow resistance
DT=20K
DT=10K
mbar
mbar
0.9
6.0
3.4
19.5
Flue gas
*1
(at higher output)
Medium temperature (gross
*2
) ºC
Mass flow rate kg/h
CO
2
content in the flue gas %
160
65
13
175
105
13
Flue outlet External ∅mm 160 160
Required draught Pa
mbar
13
0.13
15
0.15
*1
Values for calculating the size of the flue system, according to DIN4705 based on 10.0%CO
2
.
*2
Flue gas temperature measured as average gross value as per EN304 at 20ºC combustion air temperature.
