Fitting roof hooks for slate cover
1. Mark the position of the roof hooks
in accordance with the dimensions
shownintheillustrationsonpage7
and 10.
2. Remove slates from the roof hook
area.
3. Secure the roof hooks on the roof
surface. Fit commercially available
lead flashing to protect against
ingress of moisture.
4. Cover the roof.
Continue with "Mounting rail instal-
lation" on page 13.
Fitting roof hooks for corrugated sheet cover
1. Mark the position of the roof hooks
in accordance with the dimensions
shownintheillustrationsonpage7
and 10.
2. Position the roof hooks at the level
ofabattenontotheridgeofthe
roofing sheet and, through the hole
in the roof ho ok, drill a fur ther hole
into the apex of the corrugatio n.
3. Secure the roof hooks with screws
7 8 mm and sea ling washe rs (on-
site provision) to the battens.
Continue with "Mounting rail instal-
lation" on page 13.
Horizontal rooftop installation (cont.)
12
5862 788 GB
