Overview Installation with mounting brackets
(e.g. on sheet ste el roofs)
A Spacer
B Connecting ch amber
C Mounting bracket
D Mounting rail with tube holder
H Mounting rail
Horizontal rooftop installation (cont.)
8
5862 788 GB
