Combination
(tubes)
ammbmmcmmdmme mm
20 1439 — 850 ——
30 2149 — 1260 ——
20/20 1439 1439 850 1465 2 315
20/30 1439 2149 850 1820 2 875
30/20 2149 1439 1260 1820 2875
30/30 2149 2149 1260 2175 3435
Secure the mounting b rackets to the
substructure in accordance with the
dimensions given in the illustration on
page 8 and 10.
