ViewSonic CDE6520-W - 11 Technical Specifications; Cde6520 Cde6520-W

36
11. Technical Specifications
11.1. CDE6520/CDE6520-W
Display:
Item Specications
Screen Size (Active Area) 165 cm / 65 inch
Aspect Ratio 16:9
Number of Pixels 3840 (H) x 2160 (V)
Pixel Pitch 0.372 (H) x 0.372 (V) [mm]
Displayable Colors 10bit, 1.07 Billion colors
Brightness 450 cd/m²
Contrast Ratio (Typical) 1200:1
Viewing Angle 178 degrees
In/Out Terminals:
Item Specications
Speaker Output Internal Speakers
16W (L) + 16W (R) [RMS]/8Ω
1 Way 1 Speaker System
82 dB/W/M/160 Hz ~ 13 KHz
Audio Output 3.5mm Jack x 1 0.5V [rms] (Normal) / 2 Channel (L+R)
Audio Input 3.5mm phone jack x 1 0.5V [rms] (Normal) / 2 Channel (L+R)
RS232C D-Sub Jack x 1 (9 pin) TXD + RXD (1:1)
RJ-45 RJ-45 Jack x 1 (8 pin) 10/100 LAN Port
HDMI Input
HDMI Jack x 2 (Type
A) (19 pin)
Digital RGB: TMDS (Video + Audio)
MAX: Video - 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)
Audio - 48 KHz/ 2 Channel (L+R)
Supports LPCM only
DisplayPort in
DisplayPort
Jack x 2 (20 pin)
Digital RGB: TMDS (Video + Audio)
MAX: Video - 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)
Audio - 48 KHz/ 2 Channel (L+R)
Supports LPCM only
VGA Input
D-Sub Jack x 1
(15 pin)
Analog RGB: 0.7V [p-p] (75Ω), H/CS/V:TTL (2.2kΩ),
SOG: 1V [p-p] (75Ω)
MAX: 720p, 1080p, 1920 x 1080/60 Hz (WUXGA)
USB Input USB x 3 (Type A) USB2.0/3.0, Multimedia play and service port
General:
Item Specications
Power Input 100 - 240V~, 50/60Hz, 3.5A
Power Consumption (Max) 300 W
Power Consumption (typ.) 220 W
Power Consumption (Standby & O󰀨) <0.5 W (RS232 in active)
Dimensions (Without Stand) [W x H x D] 1450.6 x 828.1 x 78.5 mm
Weight (Without Stand) 22.95 Kg
Gross Weight (Without Stand) 33.6 Kg
