ViewSonic PA503HD - Hdmi 3 D

56
HDMI 3D
Signal Resoluon Refresh Rate (Hz)
Frame Packing
1080p
1920 x 1080 24
720p
1280 x 720 50/60
Side by Side
1080i
1920 x 1080 50/60
Top and Boom
1080p
1920 x 1080 24
720p
1280 x 720 50/60
NOTE:
• 1080i@25hz and 720p@50hz will run in 100 Hz; other 3D ming will run in
120 Hz.
• 1080P@24hz will run 144Hz (XGA, WXGA, 1080p)/96Hz (WUXGA).
• If the input frame rate is 48 Hz or greater, the output frame rate is set to
twice the input frame rate (FRC = 2X mode).
• If the 3D input frame rate is 25Hz or greater, the output frame rate is set to
four mes the input frame rate (FRC = 4X mode).
• If the 3D input frame rate is 24Hz (includes 23.9Hz), the output frame rate
is set to six mes the input frame rate (FRC = 6X mode).
