Making Connecons
Connecng to External Devices
HDMI IN Connecon
Media Player Connecon
Connect an HDMI cable from your
external device to an HDMI IN port on
the LED display.
PC Connecon
Connect an HDMI cable from your PC
to an HDMI IN port on the LED display.
HDMI Out
HDMI In
HDMI 1 HDMI 2
Blu-ray / DVD / DVR / Media Player
HDMI Out
HDMI In
HDMI 1 HDMI 2
Audio Connecon
Connect an audio cable from your external audio device to the Audio Out port on
the LED display.
AUDIO OUT
Stereo Amplifier
AUDIO OUT
Audio In
AUDIO OUT
HDbaseT Connecon
Connect a CAT5e/6 cable from your external device to the HDbaseT device before
installing the System Control Box Cover.
HDBaseT Switch
Cat5e/6 Cable
