Display

Sub-menu Descripon

Brightness Level

Adjust the brightness level by eight (8) levels.

Ambient Light Sensor

Detects ambient light and adjusts brightness levels

automacally.

Font Size

Preview and adjust the font size on the display.

Main Page
