I. Network Setting
Connecting to Wireless LAN
1) Tap “All applications” – “Settings”.
2) Turn “Wi-Fi” to ON by dragging “OFF” to the right.
3) When Wi-Fi is turned on, a list of all available wireless LAN access points will be shown on the right
side of the screen. Tap the desired Wireless LAN access point for connection.
4) If a password is required, enter it and tap “Connect” to connect to the wireless LAN.
Connecting to RJ45
Simply plug in your Ethernet cable to the RJ45 port to connect to a LAN. No set-up or conguration is
required.
J. Formatting
Resetting Your Smart Display
Formatting will delete all of your data created and added after purchase (including system and application
settings, downloaded applications, etc.)
1) Tap “All applications” – “Settings”.
2) Tap “Back up & reset”.
3) Tap “Factory data reset".
4) Conrm all onscreen instructions and tap “reset”.
5) Again, conrm all onscreen instructions and tap “Delete All”. Formatting will begin shortly.
System will reboot several times during formatting.
K. Use as HDMI (MHL)/VGA supported Display
Depending on the mode selected, this product may be used as an HDMI (MHL)/VGA supported
display.
Android Mode Can be used as an Android device.
Display Mode
When in Display Mode, the webcam, touch-screen and USB upstream functionality requires the
USB to USB B-type cable connected to the PC, for example Window 7.
Input source selection
1) Connect the main unit and device with the HDMI-HDMI cable,
HDMI-MHL cable or VGA-VGA cable. Optional accessory; may
not be included with this product package in some territories.
2) Press the SELECT key
to choose the input source on the
OSD window.
3) Use UP ▲ and DOWN ▼ keys to select the source.
4) Press the SELECT key
again to Enter or press MENU to
exit.
Note:
1) The INPUT SELECT OSD window will close after 15 sec.
without any action.
2) If there is no signal source, press SELECT key
to choose another source.
