Getting Started
DVI Connection
☼
• If the equipment has a DVI jack and not an HDMI jack, connect the DVI jack to the HDMI
jack [2] and connect the audio jack to the AUDIO In jacks of HDMI [10].
YPbPr or Component Connection
Cable/Satellite
antenna cable
DVI-to-HDMI cable
HD cable box/
HD satellite box
Rear of Display
Audio cable
HD cable box/
HD satellite box
Cable/Satellite
antenna cable
Rear of Display
Component video cable
Audio cable
