Inside
Outside
Exit Loop
Inside Re-open Loop
Center Loop
Outside
Re-open Loop
Inside
Outside
5'
5' 5'
AA
5'
Gate in Open Position
Inside
Re-open
Loop
Center
Loop
Outside
Re-open
Loop
Exit
Loop
Make Even
with Open Gate
TECHNICAL SUPPORT 1 800 908 0884
20
VEHICULAR LOOP DETECTOR INSTALLATIONVEHICULAR LOOP DETECTOR INSTALLATION
Dimension A – 5’ for Single Gate Operator
6’ for Master/Slave Gate Operator
Note: Not all loops may be necessary
for every installation. Check local
regulations and accepted best-
practice design requirements.
