2.1 General
This instruction manual constitutes
original manufacturer's instructions in
the sense of EC Directive 2006/42/EC.
VIKING is continually striving to further
develop its range of products; we therefore
reserve the right to make alterations to the
form, technical specifications and
equipment level of our standard
equipment.
For this reason, the information and
illustrations in this manual are subject to
alterations.
This instruction manual is protected by
copyright. All rights reserved, especially
the right of reproduction, translation and
processing using electronic systems.
4.1 General
These safety regulations must
be observed when working with
the machine.
Read the entire instruction
manual before using the
machine for the first time. Keep
the instruction manual in a safe
place for future reference.
Also carefully read the entire instruction
manual for the VIKING gardening power
tool, in particular the section "For your
safety", prior to initial operation of the
engine.
The engine must only be started and
stopped as described in the instruction
manual for the VIKING gardening power
tool.
An ignition spark is generated when
starting the engine. For that reason, never
start the engine in the vicinity of gas leaks
or natural gas deposits and do not use
pressurised starting fluids.
The recoil starter rope is retracted and
recoiled after the engine starts. This
kickback can pose a risk of injury to hands
and arms.
Movement of the work tool on the VIKING
gardening power tool can start the engine
and generate an ignition spark. For that
reason, detach the spark plug socket
before performing any maintenance
operations on the engine. Keep the spark
plug socket away from the spark plug; an
inadvertent ignition spark can result in fires
or electric shocks. Ignition spark testing
should only be performed using a tested
spark tester.
Only maintenance operations described in
this instruction manual may be carried out
on the engine. Have all other work
performed by a specialist dealer. VIKING
recommends VIKING specialist dealers.
1. Table of contents
Notes on the instruction manual 7
General 7
Machine overview 7
For your safety 7
General 7
Description of symbols 8
Preparing the machine for
operation 8
Checking the oil filling level and
adding engine oil 8
Refilling the tank 9
Maintenance 9
Maintenance schedule 9
Checking and cleaning the air
filters 9
Changing the engine oil 9
Checking the spark plug 10
Standard spare parts 10
2. Notes on the instruction
manual
3. Machine overview
1 Recoil starter rope handle
2 Engine hood with air vents
3 Fuel tank
4 Tank cap
5 Air filter
6 Primer
7 Carburettor
8 Spark plug socket
9 Muffler with guard plate
10 Exhaust opening
11 Oil dipstick
4. For your safety
