VIKING TECHNICAL SUPPORT 1.800.908.0884
39
TROUBLESHOOTING - STANDARD ECU
LCD Display References
LCD MSG Meaning
Page 41
TS Ref #s
Multi Meter Displays
MOT AMP
__._ A
This is the actual motor amperage during operation.
MOT VOLT
__._ VDC
This is the actual motor voltage during operation.
AC VOLT
__._ VAC
This is the actual low voltage AC to the Control Board from the transformer.
CHARGE
__._ VDC
Indicates the charging voltage to the batteries, if the Battery Switch is in the
OFF position.
BAT VOLT
__._ VDC
Indicates battery voltage, if the AC power is discontinued to the Control
Board.
Board Settings Messages
Speed
__ %
Shows the percentage of speed set by the Speed adjustment on the Control
Board. (pg 24)
OVERLAP
__ SEC
Shows the number of seconds set by the Overlap Adjustment on the Control
Board. (pg 24)
ODS SENS
___%
Shows the force setting selected to trip the obstruction sensor. (pg 24, 26)
TIMER
__ SEC
Shows the amount time set or remaining to hold the gate at the Open Limit
position, before the gate starts to close. (pg 24)
HEATER
__ OFF
The Integrated Heater is disabled for the open “OPN” and/or close “CLS”
limits (pg 27)
HEATER
__ ON
The Integrated Heater has been enabled to turn on at the open “OPN” and/or
close “CLS” limits (pg 27) “ACTV” will also be displayed while it is heating.
