VIKING TECHNICAL SUPPORT 1.800.908.0884
50
TROUBLESHOOTING - SOLAR ECU
LCD Display References
LCD MSG Meaning
Page 51
TS Ref #s
Error Messages
Er PANEL
LOW
Indicates that the voltage being provided from the solar panel is too low.
1, ?
ER PANEL
HIGH
Indicates that the voltage being provided from the solar panel is too High.
1, ?
ER SOLAR
NO PANEL
Indicates that there is no voltage being provided from the solar panel.
1, ?
ERR NO
Sol UNIT
Solar board can’t detect a solar gate operator.
6
ERR CHRG
HIGH
Indicates the Solar Panel voltage is high or potential problem with the Solar
Charger.
1, 2, ?
ERR BAT
LOW
The battery is low
1, 2, 3,
?
ERR FUSE
15 AMP
15 Amp motor fuse is blown on the Primary or Single Control Board.
7, 11, 12
ERR FUSE
15A S
15 Amp motor fuse is blown on the Secondary Module.
7, 11, 12
ERR REFV
WRONG
One, or more, of the internal reference voltages are incorrect.
?
ERR SENS
UL RO
There is a problem with the required monitored sensor(s) connected
to the “UL” and/or “Re-Open” input terminals (pg 16, 20-21).
20
ERRLIMIT
OPN+CLS
There is a problem with the Limit Switches or Wires. 22
